Exterior Elevations: show the front, rear and sides of the house, including exterior materials, details and measurements.
Foundation Plans: All necessary notations and dimensions are included. (Foundation options will vary for each plan. If the home you want does not have the type of foundation you desire, contact Familyhomeplans.com of your plan.)
Interior Elevations: (call 1-800-235-5700 before ordering to confirm availability) show the specific details of cabinets (kitchen, bathroom). We suggest contacting local cabinet and fireplace distributors for sizes and styles.
Schematic Electrical Layouts: (call 1-800-236-5700 before ordering to confirm availability) show the suggested locations for switches, fixtures and outlets. These details may be shown on the floor plan or on a separate diagram.
Detailed Floor Plans: show the placement of interior walls and the dimensions for rooms, doors, windows, stairways, etc., of each level of the house.
Due to regional variations, local availability of materials, local codes, methods of installation, and individual preferences, it is impossible to include detail on heating and plumbing work on your plans. The duct work, venting, and other details will vary depending on the type of heating and cooling system (forced air, hot water, electric, solar) and the type of energy (gas, oil, electricity, solar) that you use. These details and specifications are easily obtained from your builder, contractor, and/or local suppliers.
Want to make changes?
Receive a FREE modification estimate in one of 3 ways. Our modification team is ready to help you adjust any plan to fit your needs. The ReDesign process is simple and estimates are free!
QUICK Cost-To-Build estimates have the following assumptions:
QUICK Cost-To-Build estimates are available for single family, stick-built, detached, 1 story, 1.5 story and 2 story home plans with attached or detached garages, pitched roofs on flat to gently sloping sites.
QUICK Cost-To-Build estimates are not available for specialty plans and construction such as garage / apartment, townhouse, multi-family, hillside, flat roof, concrete walls, log cabin, home additions, and other designs inconsistent with the assumptions outlined in Item 1 above.
User is able to select and have costs instantly calculate for slab on grade, crawlspace or full basement options.
User is able to select and have costs instantly calculate different quality levels of construction including Economy, Standard, Premium. View Quality Level Assumptions.
Estimate will dynamically adjust costs based on the home plan's finished square feet, porch, garage and bathrooms.
Estimate will dynamically adjust costs based on unique zip code for project location.
All home plans are based on the following design assumptions: 8 foot basement ceiling height, 9 foot first floor ceiling height, 8 foot second floor ceiling height (if used), gable roof; 2 dormers, average roof pitch is 12:12, 1 to 2 covered porches, porch construction on foundations.
Summarized cost report will provide approximately 70 lines of cost detail within the following home construction categories: Site Work, Foundations, Basement (if used), Exterior Shell, Special Spaces (Kitchen, Bathrooms, etc), Interior Construction, Elevators, Plumbing, Heating / AC, Electrical Systems, Appliances, Contractor Markup. View a LIVE Sample Cost Report.
QUICK Cost-To-Build generates estimates only. It is highly recommend that one employs a local builder in order to get a more accurate construction cost.
All costs are "installed costs" including material, labor and sales tax.
* Limit one $19.95 credit per complete plan package order.
** Available for U.S. only.
Previous Q & A
Previous Questions and Answers
Q:Does this plan include interior elevations and schematic electrical layout? Is there a materials list available?
A:The plans include none of those .
Date Posted: 31-Mar-21
Q:Do you offer DWG plan format?
A:Yes we do
Date Posted: 26-Jan-21
Q:Can this plan be used on a level lot?
The plan as to be built on a sloped lot , otherwise you will have to modify it .
Date Posted: 22-Jul-19
Q:Is there a detached garage plan you can recommend to go along with this home design?
A:I'm sorry, no we don't.
Date Posted: 02-Jul-18
Q:I'm a DIY 1st time owner builder, love this look but I can't see enough detail here to make a decision before purchasing the plan,I would also want to add some footage by stretching the overall length about 16 feet, not changing the 24' span.do you have anymore photos or drawings you can share with me to help me get a better understanding of the structure, I'm not try to cheat on buying your plan just can't see quite enough detail to buy yet, thanks Glen Bronson
We don't have any more image for this model .
Date Posted: 19-Feb-18
Q:Is this designed to be built with wood or steel frame? Can I use either? Any known issues building it a snowy climate like Michigan? If I pay for the license-to-build, can i take the plan and make the floor plan bigger. I do need to move the washer dryer to the main floor somewhere.
The plan is designed with wood frame .
There is no problem building it in snowy area , unless the roof joist( pre-fab) are calculeted for it .
We offer the modification services , but you can ask a local designer to do so .
Date Posted: 25-Apr-17
Q:Could a place for a washer and dryer be put on the first floor if so,where?
A:They're is no convenient place to put washer/dryer on main floor.
Date Posted: 17-Apr-15
Q:Could this be engineered for a flat view lot? Seems a little limited the way the layout is now, lends itself to a lot of excavating unless your lots land naturally fit the design
A:This plan have been design for a sloped lot . it could be modify ,but in this case all the living area (Kitchen , dining , living) would be upstairs .
Date Posted: 28-Oct-14
Q:can this plan be set up on a flat surface? To avoid a lot of excavation? Or is it meant foe a sloped surface?
A:it as to be build on a sloped lot.
Date Posted: 05-May-14
Q:Has anyone ever done just the top floor configuration? S;ab on grade . or on piers etc..and forgaone the basement layout and excess rooms?
A:we never sold this plan as a 1 storey house .
Date Posted: 05-May-14
Q:If I order the PDF file, can I build unlimited times? If not, what was is the reuse fee?
Do the plans come stamped by an engineer?
A:Unlimited Build License issued on Reproducible Set, PDF File or CAD File orders, depending on availability.
The plans are not stamped by an engineer
Date Posted: 20-Jun-12
Q:Can I make modifications to this plan?
A:Yes you can! Please click the "Modifications" tab above to get more information.
Q:What is the estimated price to build this plan?
A:The national average for a house is running right at $125.00 per SF. You can get more detailed information by clicking the Cost-To-Build tab above. Sorry, but we cannot give cost estimates for garage, multifamily or project plans.
