Plan 93483 Order Code: C101
Traditional Style House Plan 93483
2156 Sq Ft, 3 Bedrooms, 3 Full Baths, 3 Car Garage
Quick Specs
2156 Total Living Area2352 Lower Level
2156 Main Level
1535 Bonus Area
3 Bedrooms
3 Full Baths
3 Car Garage
71'2 W x 64'6 D
Quick Pricing
PDF File: $1,445.005 Sets: $1,448.00
5 Sets plus PDF File: $1,650.00
8 Sets: $1,495.00
CAD File: $1,650.00
Plan Specifications
Specifications
| Total Living Area: | 2156 sq ft |
| Lower Living Area: | 2352 sq ft |
| Main Living Area: | 2156 sq ft |
| Bonus Area: | 1535 sq ft |
| Unfinished Basement Area: | 2352 sq ft |
| Garage Area: | 720 sq ft |
| Garage Type: | Attached |
| Garage Bays: | 3 |
| Foundation Types: | Basement Crawlspace - * $437.50 Slab - * $437.50 Walkout Basement |
| Exterior Walls: | 2x4 2x6 - * $437.50 |
| House Width: | 71'2 |
| House Depth: | 64'6 |
| Number of Stories: | 1 |
| Bedrooms: | 3 |
| Full Baths: | 3 |
| Max Ridge Height: | 25'4 from Front Door Floor Level |
| Primary Roof Pitch: | 8:12 |
| Roof Framing: | Stick |
| Porch: | 380 sq ft |
| Deck: | 230 sq ft |
| Formal Dining Room: | Yes |
| FirePlace: | Yes |
| 1st Floor Master: | Yes |
| Main Ceiling Height: | 9' |
| Upper Ceiling Height: | 8' |
Special Features:
Plan Package Pricing
Pricing
Available Foundation Types:
Available Exterior Wall Types:
Prices subject to approval prior to fulfillment.What's Included?
What is Included in this House Plan?
Foundation Plans: include drawings for a standard, daylight or partial basement, crawlspace, pier, or slab foundation. All necessary notations and dimensions are included. (Foundation options will vary for each plan. If the home you want does not have the type of foundation you desire, contact us to discuss having that plan created.)Detailed Floor Plans: show the placement of interior walls and the dimensions for rooms, doors, windows, stairways, etc., of each level of the house. In some cases, the door and window dimensions and/or stair details may be on a separate page.
Exterior Elevations: show the front, rear and sides of the house, including exterior materials, details and measurements.
Wall Sections and/or Cross Sections: show details of the house as though it were cut in slices from the roof to the foundation. The cross sections specify the home's construction, insulation, flooring and roofing details.
Roof Details: show slope, pitch and location of dormers, gables and other roof elements, including clerestory windows and skylights. These details may be shown on the elevation sheet or on a s eparate diagram. Note: If trusses are used, we suggest using a local truss manufacturer to design your trusses to comply with your local codes and regulations.
Standard Construction Details: various details related to beam support, floor construction, connections, and roofing options.
The following may also be included:
Interior Elevations: show the specific details of cabinets (kitchen, bathroom, and utility room), fireplaces, built-in units, and other special interior features, depending on the nature and complexity of the item. Note: To save money and to accommodate your own style and taste, we suggest contacting local cabinet and fireplace distributors for sizes and styles.
Schematic Electrical Layouts: show the suggested locations for switches, fixtures and outlets. These details may be shown on the floor plan or on a separate diagram.
Plan Modifications
Want to make changes?
Receive a FREE modification estimate in one of 3 ways. Our modification team is ready to help you adjust any plan to fit your needs. The ReDesign process is simple and estimates are free!1. Complete this On-Line Request Form
2. Print, complete and fax this PDF Form to us at 1-800-675-4916.
3. Want to talk to an expert? Call us at 913-938-8097 (Canadian customers, please call 800-361-7526) to discuss modifications.
Note: - a sketch of the changes or the website floor plan marked up to reflect changes is a great way to convey the modifications in addition to a written list.
We Work Fast!
When you submit your ReDesign request, a designer will contact you within 24 business hours with a quote.
You can have your plan redesigned in as little as 14 - 21 days!
We look forward to hearing from you!
Start today planning for tomorrow!
Cost To Build
QUICK-Cost-To-Build Estimate
View an actual, LIVE cost report. This report is for demo purposes only. Not plan specific.
$24.95 per plan
** Available for U.S. only.
QUICK Cost-To-Build estimates have the following assumptions:
QUICK Cost-To-Build estimates are available for single family, stick-built, detached, 1 story, 1.5 story and 2 story home plans with attached or detached garages, pitched roofs on flat to gently sloping sites.QUICK Cost-To-Build estimates are not available for specialty plans and construction such as garage / apartment, townhouse, multi-family, hillside, flat roof, concrete walls, log cabin, home additions, and other designs inconsistent with the assumptions outlined in Item 1 above.
User is able to select and have costs instantly calculate for slab on grade, crawlspace or full basement options.
User is able to select and have costs instantly calculate different quality levels of construction including Economy, Standard, Premium. View Quality Level Assumptions.
Estimate will dynamically adjust costs based on the home plan's finished square feet, porch, garage and bathrooms.
Estimate will dynamically adjust costs based on unique zip code for project location.
All home plans are based on the following design assumptions: 8 foot basement ceiling height, 9 foot first floor ceiling height, 8 foot second floor ceiling height (if used), gable roof; 2 dormers, average roof pitch is 12:12, 1 to 2 covered porches, porch construction on foundations.
Summarized cost report will provide approximately 70 lines of cost detail within the following home construction categories: Site Work, Foundations, Basement (if used), Exterior Shell, Special Spaces (Kitchen, Bathrooms, etc), Interior Construction, Elevators, Plumbing, Heating / AC, Electrical Systems, Appliances, Contractor Markup. View a LIVE Sample Cost Report.
QUICK Cost-To-Build generates estimates only. It is highly recommend that one employs a local builder in order to get a more accurate construction cost.
All costs are "installed costs" including material, labor and sales tax.
* Limit one $24.95 credit per complete plan package order.
** Available for U.S. only.
Previous Q & A
Previous Questions and Answers
A: Guest bathroom – 7.5 x 5 Foyer – 6x6 Master bathroom – 9.25x13 Yes, the wall between kitchen and family room is load bearing.
A: Yes, the wall is load bearing. So a beam will need to be engineered to span the length needed.
A: Please see attached.
View Attached FileA: There are no load bearing walls at the bathroom.
A: The mechanicals would need to go in the attic space or garage if not using the basement option.
A: I regret that there are no further images or photos on this design.
A: No plumbing, but yes – plans include the electrical schematics. Client should consult mechanical contractor for best location to relocate the mechanical room.
A: Stairs are 3’-4” wide
A: None of the derivatives have solid brick exteriors.
A: Yes, an unfinished basement is available. Simply express that you want the unfinished basement option when ordering.
A: Removing the vault in the family room and expanding the bonus level would be a custom modification. I regret that we do not have a version with only one bedroom on the bonus level. That can easily be done in the field with the builder. Lastly, the roof system is framed using rafters.
A: Only above the “F” in Future noted on the upper floor plans. And even that will only have an opening about 42” in height.
A: Assuming you are needing the rear of the house exposed being on the hill side (or sloped side), the plan already comes as a rear walkout. The design also comes standard as an unfinished basement. The finished basement option is optional. Simply request the unfinished basement version when ordering. As for the pocket doors, pocket doors require about 2/8 to 3/0 of room beyond the door in the wall for the pocket frame. Subsequently, any door that has that amount of space in the wall beyond the door opening, it can be changed to a pocket door.
A: I regret that there is no virtual tour for this design.
A: Tub is 6x3
A: Windows are 2-8x5-2 across the front.
A: Dimensions (Apx.):
Foyer: 6’ x 6’
Mstr. Bath: 9’4 x 13’
Bath #2: 7’7 x 5’
Bath #3: 7’5 x 5’
A: Yes, The side entry garage would make this plan perfect for a corner lot. Jim
Common Questions:
A: Yes you can! Please click the "Modifications" tab above to get more information.
A: The national average for a house is running right at $125.00 per SF. You can get more detailed information by clicking the Cost-To-Build tab above. Sorry, but we cannot give cost estimates for garage, multifamily or project plans.
